The MTA0007 is single operational amplifier with low
noise and low offset voltage. This amplifier has the
characteristics of wide supply voltage range, low
power and stable high frequency response. This
amplifier achieves very good AC performance with
2.1MHz bandwidth, 0.1V/μs slew rate and low
distortion while drawing only 1.67mA of quiescent
current per amplifier. This amplifier has the
characteristics of low input bias current and high
open-loop gain. The MTA0007 has a very low input
offset voltage, which is obtained by trimming during
the wafer stage. These low offset voltages usually
eliminate any need for external zeroing.
MTA0007 has wide temperature range from -55°C to
Single or dual supplies as low as 6V(±3V) and up to
36V(±18V) can be used.
