ML-3865-3526-B1H1 is high performance bottom-port analog silicon microphone that
receives the sound signal from the backside hole on PCB. By usingourown innovative
and unique MEMS silicon microphone chip design, MicroLink Senstech provides a
series of packaged MEMS silicon microphones with compact size to achieve good
performance such as high SNR, high sensitivity, excellent reliability and broad
frequency response. This series of MEMS microphones find wide applications in cell
phones, tablets, wearable devices and other portable electronic devices.
The ML-3865-3526-B1H1 has a sensitivity of -38dBV/Pa(tolerance of ±1dBV/Pa) with
a signal-to-noise ratio of 65 dB,an extreme low total harmonic distortion of 0.1%
at 94 dB SPL and very high acoustic overload point of 123 dB SPL.
